Specification

Applications

1.Warehousing: Pallet handling, stacking, loading/unloading
2.Logistics: Port terminals, freight yards, distribution centers
3.Manufacturing: Raw material transport, finished goods handling
4.Construction: Building material transport, site logistics
5.Agriculture: Grain handling, warehouse stacking, bulk cargo moving

Key Configurations

Engine: Isuzu engine, stable & durable, low‑failure operation Hydraulic System: Precision‑controlled pumps and valves for smooth lifting and tilting Mast: 2‑stage mast, 4.5‑meter lifting height Cab: Ergonomic ROPS‑certified overhead guard, open cabin (air‑conditioning optional) Fork & Attachments: Standard fork length, optional side shifter, fork positioner or clamp attachments Control System: Instrument panel with hour meter, engine warning indicators, fault reminder, equipped with Toyota SAS stability safety system

Full Technical Specifications

Performance Parameters

• Rated capacity: 10000 kg @600 mm load center
• Standard max lift height: 3000 mm
• Optional mast: 3500‑6000 mm 2‑stage / 3‑stage mast
• Mast tilt: Forward 6° / Backward 12°
• Travel speed (no‑load): 24 km/h
• Travel speed (loaded): 21 km/h
• Max climbing gradient: 25%
• Transmission: Powershift automatic transmission

Overall Dimensions

• Overall length (without forks): 4150 mm
• Overall width: 2180 mm
• Overhead guard height: 2620 mm
• Minimum outer turning radius: 3850 mm
• Fork dimension: 1500×180×80 mm (L×W×T)

Power & Tires

• Engine: Isuzu diesel engine
• Rated power: 92 kW
• Fuel tank capacity: 160 L
• Tires: Pneumatic tires, solid tires optional

Weight

• Service weight: Approx. 13800 kg

Note: The actual capacity will drop when equipped with high mast or extra attachments.

Pre-Delivery Inspection Items

1. Engine Related Systems Check for component contamination, brake fluid level and condition, battery status and other related parts.

2. Forklift Handling Equipment Inspect mast, lifting slings, lifting chains and other loading & unloading accessories.

3. Power Transmission System Inspect clutch pedal, transmission and torque converter.

4. Hydraulic System Inspect hydraulic tank, oil pipelines, hydraulic cylinders and related components.

5. Running Gear Equipment Inspect tires, wheel hubs and other walking parts.

6. Braking System Inspect service brakes and parking brakes.

7. Control System Inspect steering wheel, power steering system and steering linkage.

8. Safety Devices Inspect safety helmets, working lights, instrument panels and other safety accessories.

9. Comprehensive Inspection & Cleaning Perform full-scale equipment inspection and overall cleaning.
